en Laser Cleaning Machine Wattsan CW 6000 - Wattsan
To catalog
wattsan-img

Laser Cleaning Machine Wattsan
CW 6000

  • Laser source
  • Cooling system
  • Cleaning head weight
  • Fiber length
  • Control
  • Types of cleaning patterns
  • 6000 W (JPT/Raycus)
  • Water
  • 2,2 kg
  • 20 m
  • Relfar-(V4) RuiDa
  • ━
All characteristics
Package list

Whatsapp
Get a price
afactory
afactory
afactory
afactory
features
features
features
features
features
partners
partners
partners
partners
partners
partners
client
client
client
client
wattsan-img
wattsan-img
wattsan-img
wattsan-img

Efficient Cleaning with Relfar

The Relfar FWH60-C30A Laser Gun is the latest development in laser cleaning technology. With its powerful performance, it efficiently cleans large surfaces, removing rust, paint, and coatings. Designed for high-output industrial use, it ensures maximum coverage and reliability.

Wider coverage

With a source power of 6 kW and a line width of 200 to 500 mm, it allows cleaning large contaminants in large areas in a short time.

High threshold optical system

The Relfar optical system allows scanning speeds of up to 40000 mm/s. This gives a high speed of cleaning of the machined surface.

Water cooling design

The efficient water cooling system combined with the S&A TEYU double circuit chiller ensures stable 24/7 operation.

Make a request

    Continuous cleaning is 2 times faster than impulse cleaning

    Continuous cleaning
    Pulse cleaning
    Continuous lasers are an excellent solution for large metal structures or pipes where rapid heat removal is required and minor damage to the base material is acceptable. Continuous laser cleaning is more cost-effective than pulsed laser cleaning. It quickly removes surface contaminants: rust, paint, especially on large areas.
    Pulsed laser cleaning removes thick contaminants from various materials, even non-metals. It does so precisely and delicately. It is often used for applications where maintaining product integrity is important, such as cleaning molds or thin materials that are sensitive to high temperatures. With adjustable pulse duration while maintaining peak power, this device allows for flexible customization of operations.
    wattsan-img wattsan-img
    wattsan-img wattsan-img

    Wattsan welding & cleaning machines are completed with well-known brands

    TEYU water cooling system
    Laser sources with options
    The water cooling unit prevents the equipment from overheating by evenly dissipating heat. Water cooling is useful for both continuous and pulsed laser sources. Even in hot weather, it cools efficiently and quietly. It works well at high power for a variety of tasks.
    For Wattsan welding and cleaning machines, you can choose a laser source such as Raycus or JPT. If you are on a tight budget and stable, high power operation is important, Raycus is a great option. The JPT with its adjustable pulse parameters may be better for precision welding where control over heat input is critical. JPT is also an excellent option for more precise cleaning.
    wattsan-img wattsan-img
    wattsan-img wattsan-img

    Wattsan Laser Cleaning Machine

    HANDHELD LASER CLEANING MACHINE | WATTSAN 300W PULSED

    Unleash the potential with the RuiDa control system
    wattsan-img

    The RDWelder app allows remote control and customisation of cleaning parameters. The simple interactive control system allows you to contain treatment libraries for different types of contamination. In the parameter settings you can adjust the scanning speed, frequency, utilization rate scanning area, the laser power and etc. Several languages to choose from: Chinese, English and Russian.

    wattsan-img

    The Relfar optical system allows you to adjust the width of the laser beam up to 500mm and the 1.5 m focal length will increase safety and ease of working over large areas.

    Advantages of Wattsan laser cleaning machines

    wattsan-img

    User-friendliness

    Training requires no prior skills or knowledge and takes only a few hours. Neither special protective clothing nor a camera in the workshop are needed to work at the machine. Preparation for cleaning takes up to 5 minutes.

    wattsan-img

    JPT or Raycus laser source

    The machine is equipped with a JPT fiber source. Other laser sources, such as Raycus, can be installed upon customer request. The source has high single pulse energy, uniform energy distribution, easy to operate and maintain. Suitable for processing in automobile manufacturing, marine industry, petrochemical industry, etc.

    wattsan-img

    TEYU water cooling

    The water cooling unit prevents the equipment from overheating by evenly dissipating heat. Water cooling is useful for both continuous and pulsed laser sources. Even in hot weather, it cools efficiently and quietly. It works well at high power for a variety of tasks.

    Series comparison

    SERIES/
    Parameters

    Laser source

    Packing size

    Laser power

    Cooling

    Operating mode

    Scanning speed

    Scanning range

    Laser frequency

    Cleaning head/Scanner MODEL

    Focal length

    Types of cleaning patterns

    slide-image

    PA

    Learn more

    JPT (MOPA)

    800*420*800 mm

    100-300 W

    Air

    Pulsed

    ≦30000 mm/s

    100 x 100 mm

    1-3000 kHz

    FWP50-P10A

    F254 mm

    ━, ┃, ◯, ✳, ⨁, ▦

    slide-image

    PW Pro

    Learn more

    JPT (MOPA)

    1075x664x1055 mm

    500 W

    Water

    Pulsed

    ≦30000 mm/s

    200 x 200 mm

    1-4000kHz

    FWP50-P20A

    F420 mm

    ━, ┃, ◯, ⚹, ⨁, ▦, 〰

    slide-image

    CW

    Learn more

    JPT/Raycus

    1075x664x1055 mm

    1500/2000/3000W

    Water

    Continuous-wave

    ≦20000 mm/s

    0-300 x 0-300 mm

    up to 20kHz

    FWH20-C20A

    F600 mm

    Line (━)

    slide-image

    CW Pro

    Learn more

    JPT/Raycus

    1075x664x1055 mm

    1500/2000/3000W

    Water

    Continuous-wave

    ≦20000 mm/s

    300 x 300 mm

    up to 20kHz

    FWH20-DC30A

    F800 mm

    ━, ┃, ◯, ✳, ⨁, ▦

    slide-image

    CW 6000

    Learn more

    JPT/Raycus

    1075x664x1055 mm

    6000W

    Water

    Continuous-wave

    40000 mm/s

    200-500 x 200-500 mm

    up to 20kHz

    FWH20-DC30A

    F1500 mm

    Line (━)

    ... ...
    Learn more Learn more
    Laser source
    Packing size
    Laser power
    Cooling
    Operating mode
    Scanning speed
    Scanning range
    Laser frequency
    Cleaning head/Scanner MODEL
    Focal length
    Types of cleaning patterns

    We ensure the smooth running of Wattsan machines

    Startup & Training
    Service & Support
    Wattsan service engineers help clients and all partners around the world via online or offline training. You can get info on maintenance, basic machine operations, tips for processing various materials, etc. We launch and train more than 100 clients monthly.
    Our service team operates across the world, and Wattsan machines are presented even in Antarctica. We offer an offline and online support system for clients, and it will be available for you throughout the whole machine’s lifespan.
    All of our equipment comes with a warranty and a guaranteed return policy.
    Startup & Training Startup & Training
    Service & Support Service & Support

    Materials

    The machine is suitable for materials

    img Dye
    img Electroplating
    img Oil paint
    img Oxide coating
    img Rusty metal
    img Rubber
    img Rust
    img Soot

    0/0

    Package list

    box-image
    1pc

    Laser safety glasses with a case

    box-image
    1pc

    Ethernet cable

    box-image
    1pc

    Hose for air connection

    box-image
    1pc

    Set of protective lenses

    box-image
    1pc

    Triangle key

    box-image
    2pc

    Keys for the front door

    Technical
    characteristics

    Hardware
    Control
    Relfar-(V4) RuiDa
    Types of cleaning patterns
    ━
    Cleaning head/Scanner MODEL
    RelFar FWH60-C30A
    Scanning speed
    ≦40000 mm/s
    Cleaning head weight
    2.2 kg
    Protective lens
    4
    Focal length
    F1500 mm
    Scan width range
    200-500 mm
    Dimensions
    Machine size
    1075 x 664 x 1055 mm
    Packing size
    1580 x 880 x 1380 mm
    Packing weight
    310 kg
    Power consumption
    35 kW
    Operating humidity range
    30-70 %
    Fiber length
    20 m
    Input voltage
    380 VAC, 50 HZ
    Operating temperature range
    5-40 ℃
    Laser source
    Laser source
    JPT/Raycus
    Laser wavelength
    1080 nm
    Laser power
    6000 W
    Cooling
    Water
    Operating mode
    Continuous-wave
    Laser frequency
    up to 20kHz
    Control System
    RuiDa
    Laser cleaning gun
    Relfar
    Laser sources
    JPT, Raycus
    Electrical system
    Siemens
    Make a request

      Logistics
      We will deliver the equipment under the most convenient conditions for you

      If the machine is not in stock when you purchase it, you must first wait for the assembly process to be completed. It can take at least three weeks (and up to six months). The delivery time itself ranges from 0 days to a month.

      We may deliver on various terms. The most popular ones are EXW, FOB, CIF, and DDP. You can have a machine delivered to your workplace, the destination port, or you can organise the delivery yourself by contacting logistics providers.

      EXW is the most basic shipment type, FOB and CIF may be considered the golden mean, and DDP is the most convenient.

      Technical
      characteristics

      Hardware
      Control
      Relfar-(V4) RuiDa
      Types of cleaning patterns
      ━
      Cleaning head/Scanner MODEL
      RelFar FWH60-C30A
      Scanning speed
      ≦40000 mm/s
      Cleaning head weight
      2.2 kg
      Protective lens
      4
      Focal length
      F1500 mm
      Scan width range
      200-500 mm
      Dimensions
      Machine size
      1075 x 664 x 1055 mm
      Packing size
      1580 x 880 x 1380 mm
      Packing weight
      310 kg
      Power consumption
      35 kW
      Operating humidity range
      30-70 %
      Fiber length
      20 m
      Input voltage
      380 VAC, 50 HZ
      Operating temperature range
      5-40 ℃
      Laser source
      Laser source
      JPT/Raycus
      Laser wavelength
      1080 nm
      Laser power
      6000 W
      Cooling
      Water
      Operating mode
      Continuous-wave
      Laser frequency
      up to 20kHz
      Control System
      RuiDa
      Laser cleaning gun
      Relfar
      Laser sources
      JPT, Raycus
      Electrical system
      Siemens
